液壓配件與維修

產品描述

 濾芯知識分享：更換濾芯的方法：1、單桶預過濾裝置濾芯的更換：a.關閉進油口球閥，打開上端蓋。（鋁合金型上端蓋需使用平口螺絲刀從側面缺口處輕輕撬開）；b.擰開排污口堵絲，排凈污油；c將濾芯上端的緊固螺母松開，操作者戴防油手套握緊濾芯，垂直向上取下舊濾芯；d.換上新濾芯，墊好上端密封圈（下端有自帶密封墊），上緊螺母；f.擰緊排污口堵絲，蓋好上端蓋（注意墊好密封圈），上好緊固螺栓。2、雙桶并聯預過濾裝置濾芯的更換：a.先關閉需要更換濾芯一側過濾器的進油閥，數分鐘后關閉出油閥，然后擰下端蓋螺栓，打開端蓋;b.打開排污閥，徹底排凈污油，防止更換濾芯時污油進入凈油腔;c.將濾芯上端的緊固螺母松開，操作者戴防油手套握緊濾芯，垂直向上取下舊濾芯;c.換上新濾芯，墊好上端密封圈（下端有自帶密封墊），上緊螺母;d.關閉排污閥，蓋好上端蓋（注意墊好密封圈），上好緊固螺栓。E.先打開進油閥，再打開排氣閥，待排氣閥出油時立即關閉排氣閥，然后打開出油閥即可;再以相同的方法對另一側過濾器進行操作。

免責聲明丨 部分內容來源網絡！本文僅供交流學習 , 版權歸屬原作者，部分圖片、內容推送時未能及時與原作者取得聯系，若來源標注錯誤或侵犯到您的權益煩請告知，我們將立即刪除.

企業介紹

公司供應攤鋪機配件，壓路機配件，銑刨機配件，攤鋪機刮板驅動軸，刮板驅動軸總成，找平儀，找平儀支架以及液壓泵和配件。還供應攤鋪機易損件，攤鋪機平衡梁，攪龍軸，踏板，輸料底板，葉片，熨平板，減速機，鏈軌，履帶板，支重輪，刮板大鏈條，輸料鏈條等。

聯系人：梁經理

聯系方式：13645201509（微信同號）

QQ：2870202745

QQ郵箱：2870202745@qq.com

網易郵箱：LS13645201509@163.com

WhatsApp:+86  13645201509

Filter knowledge sharing: Method for replacing filter element: 1. Replacement of filter element for single barrel pre filtration device: a. Close the inlet ball valve and open the upper cover. (The aluminum alloy upper end cover needs to be gently pried open from the side notch using a flat screwdriver); b. Unscrew the drain plug and drain the dirty oil completely; Loosen the fastening nut on the upper end of the filter element, and the operator should wear oil resistant gloves to grip the filter element tightly. Then, remove the old filter element vertically upwards; d. Replace the filter element with a new one, place the upper sealing ring (with a built-in sealing gasket at the lower end), and tighten the nut; f. Tighten the drain plug, cover the upper end cap (note to pad the sealing ring), and tighten the fastening bolts. 2. Replacement of filter element for dual barrel parallel pre filtration device: a. First, close the inlet valve of the filter on the side where the filter element needs to be replaced. After a few minutes, close the outlet valve, then unscrew the end cap bolt and open the end cap; b. Open the drain valve and thoroughly drain the dirty oil to prevent it from entering the clean oil chamber when replacing the filter element; c. Loosen the fastening nut on the upper end of the filter element, and the operator should wear oil resistant gloves to grip the filter element tightly. Then, remove the old filter element vertically upwards; c. Replace the filter element with a new one, place the upper sealing ring (with a built-in sealing gasket at the lower end), and tighten the nut; d. Close the drain valve, cover the upper end cap (pay attention to gasket the sealing ring), and tighten the bolts. E. First, open the oil inlet valve, then open the exhaust valve. When the exhaust valve releases oil, immediately close the exhaust valve, and then open the oil outlet valve; Operate the filter on the other side using the same method.

Disclaimer | Some content is sourced from the internet! This article is for communication and learning purposes only. The copyright belongs to the original author. Some images and content were not promptly contacted when pushed. If the source annotation is incorrect or infringes on your rights, please inform us and we will immediately delete it

Company Introduction

The company supplies paver accessories, roller accessories, milling machine accessories, paver scraper drive shaft, scraper drive shaft assembly, leveling instrument, leveling instrument bracket, hydraulic pump and accessories. We also supply vulnerable parts for pavers, including balance beams, agitator shafts, pedals, feeding base plates, blades, ironing plates, reducers, chain rails, track plates, support wheels, scraper chains, and feeding chains.

Contact: Manager Liang

Contact information: 13645201509 (same WeChat account)

QQ：2870202745

QQ email: 2870202745@qq.com

NetEase email: LS13645201509@163.com

WhatsApp:+86  13645201509
